Centrale non metallica KFRP/di FRP Rod che rinforza tecnologia di Pultruded di forma rotonda di CSM Φ2.0
Dettagli del prodotto
materiale del kfrp
,Membro di FRP
Membro di forza centrale non metallico di FRP/KFRP Rod CSM, KFRP Rod Φ2.0
Siamo produttore non metallico/fornitore del membro di forza centrale di FRP Rod in Cina, offrente il membro di forza di Pultruded FRP Rod per i cavi ottici della fibra.
Specifiche: (FRP rotondo: ∮0.4-∮5.0)
| Proprietà | Valori |
| Resistenza alla trazione (Mpa) | ≥1100 |
| Modulo di tensione (Gpa) | ≥50 |
| Resistenza alla flessione (Mpa) | ≥1100 |
| Modulo flessionale (Gpa) | ≥50 |
| Allungamento a rottura (%) | ≤4 |
|
Coefficiente del termale lineare
espansione (- 30-80℃) (1/℃) |
<8*10-6 |
| Tolleranza del diametro (millimetro) | ±2% |
| Raggio di piegamento minimo (millimetro) | 40*D |
| Densità (g/cm3) | 2.05-2.15 |
| Prova di piegatura ad alta temperatura (50D, 100℃, 120h) |
Nessun ufficio, crepa e
rottura |
| Prova di piegatura di bassa temperatura (50D, - 40℃, 120h) |
Nessun ufficio, crepa e
rottura |
| Torsione (±360°/m) | Non disintegrato |
We develop and produce Flat FRP strength member for different application.
FRP Rod Strength Member for Fiber Optic Cables FRP Rod Strength Member for Fiber Optic Cables Strength member for fiber optic cables, usually located at the center of fiber optic cables, is one important component of fiber optic cables by supporting optic fiber bundle and enhancing cables tensile strength. FRP Rod / FRP strength member is made by thermal pultrusion technique which combines complex resin as body material with glass fiber as reinforcement at a certain ratio.
Cable Strengthen Core For Fiber Optical Cables Non-Metallic FRP Rod Central Strength Member CSM Basic Info Technique: Pultrusion Type: Themosetting Plastic Profiles Diameter Ranges: 0.40 mm to 5.00 mm HS Code: 70199090 Materials: Resin, E-glass Fiberglass, Agents, etc. Applications: Central or peripheral strength member for fiber optical cables Origin: Jiangsu, China Product Description: Non-metallic FRP Rod strength member, usually located at the center or the periphery of
FRP Rod Strength Member for Fiber Optic Cables FRP Rod Strength Member for Fiber Optic Cables Strength member for fiber optic cables, usually located at the center of fiber optic cables, is one important component of fiber optic cables by supporting optic fiber bundle and enhancing cables tensile strength. FRP Rod / FRP strength member is made by thermal pultrusion technique which combines complex resin as body material with glass fiber as reinforcement at a certain ratio.
